Product Information
Product Parameters
|
Model |
QJY230B-E |
Capacity |
3 Ton |
|
Moter Performance |
2.2 kw |
Electrical Connection |
380V / 220V |
|
Lifting Time |
50 sec. |
Package Size 1# |
2855x470x720 mm |
|
Package Size 2# |
3200x555x45 mm |
Package Size 3# |
800x280x320 mm |
|
Package Size 4# |
590x240x250 mm |
N.W. / G.W. |
675 / 690 kgs |
|
QTY/20'CY |
24 PCS |
|
Sequence of Lockout Procedure
1) Notify all affected employees that a lockout is being performed for servicing or maintenance and that the lift must be shut down and locked out to perform the servicing or maintenance
2) Unload the subject lift (remove vehicle). Shut it down and assure the disconnect switch is "OFF" if one is provided on the lift.
3) The authorized lockout person operates the main energy isolation device removing power to the lift being taken out of service. Stored or residual energy (such as capacitors, springs, elevated machine members, hydraulic systems, air, or etc.) must be dissipated or restrained by methods such as grounding, repositioning, blocking, bleeding down, etc.
If this is a lockable device, the authorized lockout person places the assigned padlock on the device to prevent its unintentional reactivation. An appropriate tag is applied stating the person's name, at least 3" x 6" in size, an easily noticeably color, and states not to operate device or remove tag. If this device is a non-lockable circuit breaker or fuse, replace circuit with a "dummy" device and tag it appropriately as mentioned above.
4) Ensure that the equipment is disconnected from the energy sources' by first checking that no personnel are exposed, then verify the isolation of the equipment by operating the push button or other normal operating controls' or by testing to make certain the equipment will not operate. . Be sure to return any switches to the "OFF" position.
5) The equipment is now locked out and ready for the required maintenance or service.
Restoring Equipment to Service
1) Check the lift and the immediate area around the lift to ensure that nonessential items have been removed (clear all tools, vehicles and personnel) and that the completion of all lift components are operationally intact.
2) The authorized person can now remove the lock (or dummy circuit breaker or fuse) and tag. Activate the energy isolating device so that the lift may again be placed into operation.
成分-
優質液壓油，防止漏油
液壓系統采用高質量的油，提供更好的耐腐蝕性和高/低溫靈活性，允許單元在40華氏度和105華氏度之間的溫度下運行。
自動焊接
該閥采用細鋼焊接而成，操作方便，密封性好，性能可靠，具有自動鎖氣滴料功能。
高密度鋼材
由高級鋼材制成，并按照嚴格的質量和耐用性標準建造。
你可能也喜歡
型號
15噸專業液壓車間壓力機
10Ton液壓車間壓力機
30 ton氣動液壓瓶千斤頂
35TonPneumatic Hydraulic Bottle Jack
2Ton Hydraulic Trolley Jack
1.5/2Ton Hydraulic Trolley Jack
特點
? 安全閥
? 工業密封件
? 機器人焊接
? 激光切割框架
? 可拆卸零件托盤
? 雙速泵
? 重型H型框架由高級鋼制成，并按照嚴格的質量和耐用性標準建造
? 在徹底的化學清洗后應用無鉛漆面，以確保持久的光潔度并幫助防止生銹
? 油漆是油，油脂和污垢，易于清理
? 高質量的大直徑液壓鋼缸單元導致提高負載所需的較低油壓，有助于減少磨損并延長使用壽命
? 活塞閘板經過處理和拋光，以防止打滑
? 活塞-ram采用帶支撐環的y型聚氨酯密封圈，防止負載緩慢下降或繞過油漂移
? 液壓系統采用高質量的油，提供更好的耐腐蝕性和高/低溫靈活性，使設備能夠在40華氏度和105華氏度之間的溫度下運行
? 超長手柄包括容易抽吸力
? 專為大量商業用途而設計。
? 快速高效的空氣泵減少提升時間。
? 硬化合金電鍍ram最大的耐久性。
? 帶集成過濾器的空氣閥，密封液壓單元。
? 重型空氣馬達提供最大功率。
? 防止污染。
? Designed for heavy commercial use.
? Fast efficient air pump reduces lifting time.
? Hardened alloy-plated ram for maximum durability.
? Air valve with integrated filter, seal hydraulic unit.
? Heavy-duty air motor provides maximum power.
? Prevents contamination.
? The hydraulic technology makes lifting simple while a wider frame and internal bypass valve ensure safety.
? Safety bypass system prevents over-loading and ensures safe operation.
? Steel casters for longevity.
? The hydraulic technology makes lifting simple while a wider frame and internal bypass valve ensure safety.
? Safety bypass system prevents over-loading and ensures safe operation.
? Steel casters for longevity.
